The TPX™ Hose

TPX
TPX

TPX™

Compact, Strong, and Ready for Battle

Unique 3-ply construction

Traditionally, manufactured extruded hose can vary in thickness, becoming bulky and heavy. TPX™ utilizes a 3-ply design where the ribbed cover and smooth nitrile liner are extruded independently. The cover is inserted inside the tight-weave reinforcement, vulcanized, and then turned inside out. The liner is then inserted and the hose is vulcanized for a second time to form a bond of all three plies, guaranteeing a consistent, compact hose wall. The Snap-tite TPX™ is highly resistant to both conductive and radiant heat.

Download Data Sheet

Attack Hose
Klean

Color:

Features & Benefits
Hose Sizing & Test Standards

Features & Benefits

  • 3-ply rubber municipal fire hose with both the cover and liner made of heavy duty nitrile rubber, high tensile strength tightly woven polyester reinforcement for maximum durability and flexibility.
  • Smooth liner keeps friction loss to a minimum.
  • Nitrile rubber cover greatly increases abrasion resistance, provides long service life and the tightly woven reinforcement resists puncture.
  • Suitable for attack and soft sleeve suction applications.
  • Remains flexible at temperatures as low as -40°F (-40°C) and is resistant to ozone, oxidation, and most chemicals and petrochemicals.
  • Tighter weave allows more resistance to puncture while also being easier to pack and store.
  • Lays flat and needs less hose bed space than typical extruded hose.
  • Manufactured in accordance with NFPA 1960 Standard, latest edition within our ISO-9001:2015 certified quality assurance system.

Hose Sizing and Testing Standards

For specific data, please view and download the technical data sheet.

Compact and Consistent:

  • Attack
  • Soft Suction
  • USA Made
  • Klean Hose
  • Lifetime delamination warranty
  • 10-year warranty
  • 2-year all hazard warranty
